Ever tried to program a button to trigger a laser while using only 32KB of RAM and thought—“wow, this feels like black magic”? MicroPython is not just a trendy buzzword. It’s a way to harness Python’s simplicity in places you never thought possible: tiny, power-efficient, memory-constrained microcontrollers.
In a world increasingly surrounded by sensors, actuators, and snugly-fit embedded boards, MicroPython becomes your powerful Swiss army knife for prototyping and deploying real-world IoT systems. But if you’ve ever struggled with C/C++ toolchains or stared in dismay at brutal linker errors on Arduino IDE—this blog post is for you.
This is not your average “How to Blink an LED with MicroPython” post. We’re diving into why MicroPython is a liberating alternative for embedded developers, and we’ll build a WiFi-connected temperature display system with OTA updates using an ESP32.
Let’s stop dancing around syntax and start shipping smarter micro-applications.
🧠Why MicroPython?
Let’s start with some context. MicroPython is an implementation of Python 3 optimized to run on microcontrollers. Unlike CircuitPython (a fork by Adafruit), MicroPython is more bare-metal and lighter in memory, and fits beautifully for constrained devices.
đź’Ž Advantages:
- You can write scripts like regular Python.
- No more flashing firmware for every tiny logic change.
- Garbage collection and dynamic typing—in an MCU?!
- Immediate feedback with the REPL shell (read-eval-print loop).
- Easily extensible with C modules if needed.
But here’s the real kicker:
You can build complete IoT systems without writing a line of C.
Let me show you how.
đź› The Project: IoT Temperature Display with MicroPython on ESP32
We’ll connect a DHT22 sensor to the ESP32, read room temperature, serve it on a web dashboard, and allow OTA script updates — all in Python.
📦 Hardware Required
- ESP32 Dev Module (~$5)
- DHT22 Temperature Sensor
- 4.7k pull-up resistor
- Breadboard + jumpers
đź“Ą Installing MicroPython Firmware on ESP32
Download the latest .bin from: https://micropython.org/download/esp32/
Use esptool.py to flash it:
pip install esptool esptool.py --chip esp32 erase_flash esptool.py --chip esp32 --port /dev/ttyUSB0 write_flash -z 0x1000 esp32-xxx.bin
Once done, connect via REPL using screen or Thonny IDE.
🧪 Step-by-Step Code Breakdown
1. Connecting DHT22 and Reading Values
import machine
import dht
import time
sensor = dht.DHT22(machine.Pin(14))
while True:
try:
sensor.measure()
print("Temp:", sensor.temperature())
print("Humidity:", sensor.humidity())
time.sleep(5)
except OSError as e:
print("Sensor error", e)
Mount DHT22 output to GPIO14, VCC to 3.3V, and GND to GND.
2. Serve Sensor Data over WiFi
Let’s connect to WiFi first:
import network
def connect_wifi(ssid, password):
sta = network.WLAN(network.STA_IF)
sta.active(True)
sta.connect(ssid, password)
while not sta.isconnected():
pass
print('Connected, IP:', sta.ifconfig()[0])
Then, create a basic HTTP server:
import socket
html = """
<!DOCTYPE html><html><head><meta charset="utf-8" /><title>ESP Temp</title></head>
<body><h1>Temperature: {temp}°C</h1><h2>Humidity: {hum}%</h2></body></html>"""
addr = socket.getaddrinfo('0.0.0.0', 80)[0][-1]
s = socket.socket()
s.bind(addr)
s.listen(1)
while True:
cl, addr = s.accept()
sensor.measure()
response = html.format(temp=sensor.temperature(), hum=sensor.humidity())
cl.send("HTTP/1.0 200 OK\r\nContent-type: text/html\r\n\r\n")
cl.send(response)
cl.close()
Visit the ESP's IP in your browser—voilà , live data!
3. Add a Simple OTA (Over the Air) Update Feature
Let’s say you want to update your logic without reflashing the board. Serve a .py file from a known URL:
# updater.py
import urequests
def update_script(script_url, local_filename):
r = urequests.get(script_url)
if r.status_code == 200:
with open(local_filename, 'w') as f:
f.write(r.text)
print("Updated script.")
else:
print("Failed to download script.")
In your main loop (or via a button press), you can trigger:
update_script("http://yourdomain.com/latest_main.py", "main.py")
Reboot and you're upgraded.
🎯 Performance and Limitations
Although surprisingly powerful, MicroPython has some caveats:
- Memory constraints: objects pile up if you're careless.
- Performance not comparable to C for tight loops (consider native extensions).
- Debugging is minimal — use print extensively.
But for quick IoT prototyping and feature iteration, it’s unbeatable.
✨ Taking It Further
- Add a capacitive touch button to change modes with machine.TouchPad().
- Send data to MQTT or an InfluxDB instance.
- Combine with Microdot (like Flask but tiny) for REST APIs.
- Bundle with a VS Code + mpremote setup for full DX.
đź’ˇ Final Thoughts
If you’re aiming to build proof-of-concepts, edge-computing sensors, or educational devices, stop fighting with toolchains and compilers. Take advantage of Python’s expressiveness, and let MicroPython handle the low-level for you.
Whether you're sending data to space or monitoring your fridge, MicroPython gives you elegance and efficiency in one bite-size package.
Happy hacking in kilobytes! 🚀
